Product Details
Place of Origin: Chengdu, Sichuan
Brand Name: BONENS
Model Number: series
Payment & Shipping Terms
Model: |
WH138-1AK-3 |
Material: |
Carbon Film |
Change Method Of Resistance Value: |
X Type (linear Type) |
Allowable Deviation Of Resistance Value: |
± 20 (%) |
Contact Resistance: |
30M (Ω) |
Zero Position Resistance: |
2 (Ω) |
Rated Power: |
0.5 (W) |
Resistance Adjustment Method: |
Rotary Type |
Purpose: |
General |
Insulation Resistance: |
100 (M Ω) |
Sliding Noise: |
47m (V) |
Nominal Resistance Value: |
B500K |
Model: |
WH138-1AK-3 |
Material: |
Carbon Film |
Change Method Of Resistance Value: |
X Type (linear Type) |
Allowable Deviation Of Resistance Value: |
± 20 (%) |
Contact Resistance: |
30M (Ω) |
Zero Position Resistance: |
2 (Ω) |
Rated Power: |
0.5 (W) |
Resistance Adjustment Method: |
Rotary Type |
Purpose: |
General |
Insulation Resistance: |
100 (M Ω) |
Sliding Noise: |
47m (V) |
Nominal Resistance Value: |
B500K |
WH138-1AK-3 Potentiometer with Switch 50K Ohm Variable Resistors Single Turn Rotary Carbon Film
product name:
WH138 Potentiometer with Switch 50K Ohm Variable Resistors Single Turn Rotary Carbon Film Potentiometer
product description:
wh138-1ak-3 rotary potentiometers with metal shaft
Rotary carbon film switch potentiometer WH138-1AK-3 B500K, diameter 24mm, handle height 15mm
Model: WH138-1AK-3
Material: carbon film
Change method of resistance value: X type (linear type)
Allowable deviation of resistance value: ± 20 (%)
Contact resistance: 30M (Ω)
Zero position resistance: 2 (Ω)
Rated power: 0.5 (W)
Resistance adjustment method: rotary type
Purpose: General
Insulation resistance: 100 (M Ω)
Sliding noise: 47m (V)
Nominal resistance value: B500K
Product Features:
wh138-1ak-3 rotary potentiometers with metal shaft Features Rotary type,with switch,Better feeling,Special tapers
Product size:
Specification parameters:
| 性能说明 CHARACTERISTICS | ||
| 项 目ITEM | 规 格SPECIFICATION | |
| 电气性能 Electrical Characteristics |
工作温度Temp Range | -10℃~100℃ |
| 额定功率Rated Power | Curve B:0.5W Other curve B:0.25W | |
| 最大工作电压Max Operation Voltage | Curve B:AC 500V Other than B:AC 250V | |
| 阻值范围Resistance Range | 1KΩ～2MΩ | |
| 阻值允许偏差Allow Desistance Tolerance | ±20%(1MΩ or more30%) | |
| 转动噪声Rotational Noise | ≤47mV | |
| 终端电阻Terminal Resistance | R≥250KΩ 0.1%R max 250KΩ>R>10KΩ 200max 10KΩ≥R 100max |
|
| 电阻规律Resistance Law | A,B,C | |
| 抗电强度Dielectric | AC500V,1minute | |
| 开关接触电阻Switch contact resistance | Less than 30mΩ | |
| 开关额定功率Rated switching power | AC125V 1A,4A,6A | |
| 绝缘电阻Insulation Resistance | More than 100MΩ at DC250V | |
| 机械性能 Mechanical Characteristics |
旋转力矩Rotational Torque | 2～20 mN.m(20～200gf.cm) |
| 总旋转角度Total Rotational Angle | 300°±5° | |
| 止挡强度Shaft Stopper Strength | 6Kgf.cm | |
| 开关操作力Switch working force/torque | 150～450gf.cm | |
| 开关动作角度Switch working angle | 50°±10° | |
| 开关寿命Switch life | 10.000 times | |
| 旋转寿命Rotary life | 10,000 cycles | |
| 焊接So|dering | 235℃±5℃:≤3s | |
application area:
wh138-1ak-3 rotary potentiometers with metal shaft Multimedia,computer speaker,stereos amplifierlighting regulation etc
